Confirmation Step 1: Audio Panel Switch Confirmation (Without Car-Navigation System) [Entire Audio System]

CONFIRMATION STEP 1: AUDIO PANEL SWITCH CONFIRMATION (WITHOUT CAR-NAVIGATION SYSTEM) [ENTIRE AUDIO SYSTEM]
- Make sure the customer complain and identify either the center panel malfunction or audio unit malfunction.

How to activate audio panel switch confirmation mode
1. Turn the audio system to ON.
2. Press both POWER SW and CLOCK buttons for a second at the same time.
3. The audio panel switch confirmation mode is now activated.

Step 1-Step 3:
