A/C Compressor Bracket Removal / Installation
A/C COMPRESSOR BRACKET REMOVAL / INSTALLATION - 4.0L 1.
Remove the A/C compressor.
2.
Remove the power steering pump from the A/C compressor bracket. See POWER STEERING PUMP - 2.3L.
3.
Remove the A/C compressor bracket.
1.
Loosen the nuts.
2.
Remove the bolts and remove the bracket.
4.
To install, reverse the removal procedure.
