Liftgate Window Latch Removal/Installation

LIFTGATE WINDOW LATCH REMOVAL/INSTALLATION






NOTE: Make sure the liftgate window glass is in the raised position.

1. Remove the liftgate trim panel.
2. Disconnect the liftgate window latch ajar switch electrical connector.




3. Remove the 2 bolts and the liftgate window latch.
- To install, tighten to 12 N.m (1.2 kgf.m, 9 ft.lbf).

NOTE: Mark the position of the liftgate window latch prior to removing the liftgate window latch bolts.

4. To install, reverse the removal procedure.

NOTE: The liftgate window latch must be checked to make sure the latch is installed and aligned correctly.
