Pinpoint Test 6: Flash With Last Switch Pressed, But No Dynamic Pull Occurs At Throttle And The Speed Control Is Inoperative

Pinpoint Test 6: Flash With Last Switch Pressed, But No Dynamic Pull Occurs At Throttle And The Speed Control Is Inoperative

Normal Operation
The speed control actuator adjusts the speed control cable, which controls the throttle body.

Possible Causes
- Speed control cable
- Speed control actuator

Diagnostic Procedure

Step 1-Step 2:
