Entertainment Systems: Service and Repair




CONDENSER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.

2. Remove the following parts:
a. Rear seat Rear Seat Removal/Installation

b. Console Removal and Replacement

c. Tire house trim Tire House Trim Removal/Installation

d. Rear pillar trim Rear Pillar Trim Removal/Installation

e. Rear package side trim Service and Repair

f. Rear package center trim Service and Repair

3. Remove in the order indicated in the table.










4. Install in the reverse order of removal.
