DTC |
B1342 |
ABS HU/CM |
|
|
DETECTION CONDITION |
• The ABS HU/CM on-board diagnostic function detects control module internal malfunction.
|
||
|
POSSIBLE CAUSE |
• ABS HU/CM internal malfunction
|
||
|
|
|||
|
DTC |
B1342 |
ABS HU/CM |
|
|
DETECTION CONDITION |
• The ABS HU/CM on-board diagnostic function detects control module internal malfunction.
|
||
|
POSSIBLE CAUSE |
• ABS HU/CM internal malfunction
|
||
|
|
|||
Diagnostic Procedure
|
STEP
|
INSPECTION
|
ACTION
|
|
|---|---|---|---|
|
1
|
VERIFY NO ABS HU/CM MALFUNCTION
• Clear the DTC from the memory.
(See Clearing DTCs Procedures.)
• Start the engine and drive the vehicle at 10km/h {6.2 mph} or more.
• Is the same DTC present?
|
Yes
|
Replace the ABS HU/CM, then go to the next step.
(See ABS HU REMOVAL/INSTALLATION.)
|
|
No
|
Go to the next step.
|
||
|
2
|
VERIFY THAT NO OTHER DTCs ARE PRESENT
• Are any other DTCs present?
|
Yes
|
Go to the applicable DTC inspection.
(See DTC Table.)
|
|
No
|
DTC inspection completed.
|
||
