AR54.20-P-1259-01I Separating SAM Control Module From Fuse and Relay Box

Separating SAM Control Module From Fuse and Relay Box

Shown On Rear SAM Control Module:

1 Pry out SAM control module (N10/6, N10/7, N10/8) at the multiple plug of the fuse and relay module (K40/5, K40/6, K40/7).
To do this drive a suitable screwdriver into the recesses (A,B) and turn Screwdriver through 90 °

NOTE: Observe data plate (2) on the SAM control module

2 Pull down the SAM control module until the control module can be removed from the guide (C, D).
