GF80.20-P-4012SK Relock, Function

GF80.20-P-4012SK Relock, Function

The automatic relocking is actuated by the EIS control unit (N73) if the vehicle is unlocked and none of the doors or trunk lid are opened within 40 s
In this case, the vehicle relocks automatically.
The relocking feature is not indicated with visual feedback from the Antiturn signal lamps (E1e5, E2e5, E3e1, E4e1) and turn signal lamps (E6/5, E6/6).

The door status (signal of left door contact switch (S17/3) and right door contact switch (S17/4)) is transmitted by the rear SAM control module with fuse and relay module (N10/2) via CAN B.

The anti-theft alarm (ATA) (on vehicles with code (551a) Antiturn theft alarm (ATA)) is thereby always armed.
