GF27.10-P-3024N Oil Level Control, Function

GF27.10-P-3024N Oil Level Control, Function
TRANSMISSION 722.9 in MODEL 209, 211, 215, 219, 220
TRANSMISSION 722.9 in MODEL 171.4, 203, 230 up to Model Year 2008
TRANSMISSION 722.9 in MODEL 463.303 /340 /341 up to 31.5.12

The oil level control seals the openings between the oil chamber and gear seat chamber so that the rotating gear sets do not churn in the oil as the oil level increases.

The oil level control reduces power loss and prevents oil from being thrown out of the transmission housing at high oil temperatures.
