GF27.60-P-3014N Lubrication Pressure, Function

GF27.60-P-3014N Lubrication Pressure, Function
TRANSMISSION 722.9 in MODEL 171.4, 203, 230 up to Model Year 2008
TRANSMISSION 722.9 in MODEL 209, 211, 215, 219, 220
TRANSMISSION 722.9 in MODEL 463.303 /340 /341 up to 31.5.12

Excess oil is diverted to the lubrication pressure regulating valve at the working pressure regulating valve and from there used in a regulated manner for lubricating and cooling the mechanical transmission parts and torque converter. In addition the pressure in the torque converter is limited via the lubrication pressure.
