GF27.60-P-3017G Regulating Valve Pressure, Function
GF27.60-P-3017G Regulating valve pressure, function
- TRANSMISSION 722.6
Operation
The regulating valve pressure is regulated at the regulating valve pressure regulating valve depending on the working pressure up to a maximum pressure of 8 bar. It supplies the modulating pressure regulating solenoid valve (Y3/6y1), the shift pressure regulating solenoid valve (Y3/6y2) and the shift valve pressure regulating valve.
