AR35.31-P-0550-20T Pressing Tapered Roller Bearing Inner Races Onto Differential
AR35.31-P-0550-20T Pressing tapered roller bearing inner races onto differential
- Rear axle center assembly dia. 198 [models 171.456, 211.056/256 up to 31.5.06, 211.065/082/087]
Component Identification:
Component Identification:
1 Press tapered roller bearing inner races (11b) onto differential housing using assembly arbor (047) 116 589 08 61 00.
Use assembly arbor (046) 116 589 18 61 00 as a support in vise to prevent damage to roller cage of second tapered roller bearing inner race.
