Oil Pan, Engine






Oil Pan





Tighten the upper oil pan bolts in the order as shown.
^ Bolt No. 10, 11, 18 indicate a double tightening in the sequence of bolt No.s 1, 2, 3.

NOTE: Refer below for specified bolt sizes:
M6 x 20 mm (0.79 inch): No. 19, 20
M8 x 25 mm (0.98 inch): No. 1, 3, 4, 9
M8 x 45 mm (1.77 inch): No. 2, 5, 6, 7, 8, 17
M8 x 100 mm (3.97 inch): No. 12, 13, 14, 15, 16





Apply Genuine Silicone RTV Sealant, or equivalent to the lower oil pan.
^ Refer to RECOMMENDED CHEMICAL PRODUCTS AND SEALANTS, and Precautions for Liquid Gasket.





Tighten the lower oil pan bolts in the numerical order shown.
