Wiper Switch: Service and Repair
Fig. 7 Wiper switch removal. Toronado:
TORONADO
1.
Remove steering wheel,
turn signal switch and ignition lock as outlined.
2.
Remove screws securing upper mast jacket cover and the cover assembly.
3.
Remove switch and pivot from cover as shown in
Fig. 7. 4.
Reverse procedure to install.
