With Air Conditioning
Blower Motor Module:
REMOVE OR DISCONNECT 1.
Negative battery cable.
2.
Drive belt(s).
3.
Two power steering mount bolts and set aside.
4.
Blower motor.
5.
Fan.
INSTALL OR CONNECT 1.
Fan to
blower motor.
2.
Blower motor.
3.
Blower motor screws.
4.
Wiring connector.
5.
Power steering pump and drive belt.
6.
Negative battery cable.
