Instrument Cluster Indicator(S) Will Not Turn Off

Instrument Cluster Indicator(s) Will Not Turn OFF:




CIRCUIT DESCRIPTION
This test determines if the Instrument Cluster is reading the information from the Class 2 device and if the scan tool is capable of turning off or on indicators within the Instrument cluster. Certain indicators are excluded from this procedure.
^ SIR
^ Check Engine
^ Right Hand Turn Signal
^ Left Hand Turn Signal
