Blower Motor Switch: Service and Repair

Heater Control Assembly:

REMOVE OR DISCONNECT
1. Negative battery cable.
2. Radio trim plate.
3. Sound insulator.
4. Console extension.
5. A/C control assembly.
6. Electric and vacuum connections.
7. Blower switch.

INSTALL OR CONNECT
1. Blower switch.
2. Electric and vacuum connections.
3. A/C control assembly.
4. Console extension.
5. Sound insulator.
6. Radio trim plate.
7. Negative battery cable.
