Exterior Lighting Module: Service and Repair
Description:
Remove or Disconnect
1. Left and right sound insulators.
2. Slide LCM left from retainer while holding onto lock tab.
3. Connectors.
4. LCM.
Install or Connect
1. Connector.
2. Slide LCM into retainer, push to the right to engage.
3. Left and right sound insulators.
