Troubleshooting Hints

^ Make the following checks before beginning System Diagnosis.
1. Check wiper fuse 14. If open, check for short to ground through CKT 143 and replace fuse.
2. Check that all system electrical connectors are mated correctly.
3. If washer does not operate, check that:
- washer reservoir is filled.
- Hoses are correctly attached.
- Hoses are not cut, pinched or kinked.
- Nozzles are not clogged.
- Connector seal at washer pump is not damaged or missing.
4. Check for binding or broken wiper arm linkage.
^ Refer to System Diagnosis.
