Instrument Panel Compartment - Door Stop Replacement

STOP REPLACEMENT - I/P COMPARTMENT DOOR

REMOVAL PROCEDURE




1. Open the instrument panel (I/P) compartment.
2. Disengage the compartment door stop using the following procedure:
1. Press the upper door stop (2) toward the center of the vehicle.
2. Rotate the door away from the compartment.




3. Rotate the door stop to the right.




4. Remove the door stop.

INSTALLATION PROCEDURE




1. Position the door stop to the I/P compartment door.




2. Rotate the door stop to the left.




3. Engage the door stop using the following procedure:
1. Press the upper door stop (2) toward the center of the vehicle.
2. Rotate the door up to the compartment.
4. Close the I/P compartment.
