Engine Temperature Sensor: Description and Operation
ENGINE TEMPERATURE SENSOR The
engine temperature sensor is screwed into the cylinder head of the third cylinder. It has two electrical connections, i.e. corrosion on the temperature sensor threads has no detrimental effect on the resistance characteristics and, hence, on the mixture composition (potential free temperature sensor).
