Heating and Air Conditioning: Specifications
Technical data for the air-conditioning systemCompressor type 7 SB 16Refrigerant quantity
850 g refrigerant
R 134aRefrigerant oil in the compressor
195 +/- 15 cu.cm ND 8
NOTE: When installing the refrigerant lines, the screw connections and the O-rings must be wetted with
refrigerant oil.
The
refrigerant oil must be disposed of as special-category waste.
