Water Pump
WM 195019 Removing and installing coolant pump on DFI enginesCoolant pump
Tighten fastening screws.
Tightening sequence for coolant pump
Tighten the three fastening screws on the coolant pump pulley. Block the pulley with a holder Nr.38 if necessary.
Tightening torque:
23 Nm (17 ftlb.)
Fastening screws for coolant pump pulley
