Cruise Control Switch: Service and Repair

Switch, Cruise Control

To remove
1. Turn the steering wheel and undo the two screws.





2. Undo the lower screw.
3. Remove the covers. Pay attention to the catch on the covers (applies when fitting also).
4. Unplug the connector.
5. Remove the switch.

To fit
1. Position the switch.





2. Spray the connector with Kontakt 61 (part no. 30 04 520) and plug it in.
3. Fit the covers. Pay attention to the catch on the covers.
4. Tighten the lower screw.
5. Turn the steering wheel and fit the two screws to the steering column cover.
