Wiper Motor Module Grommet Replacement (Front)
WIPER MOTOR MODULE GROMMET REPLACEMENT (FRONT)REMOVAL PROCEDURE 1.
Remove the front
wiper motor.
2.
Remove the washer solvent filter grommet from the pump.
INSTALLATION PROCEDURE 1.
Install the washer solvent filter grommet to the pump.
IMPORTANT: The metal bushing inserts need to be installed with the flat side underneath the module bolts.
2.
Install the front
wiper motor.
