Intake Manifold
Intake Manifold-to-Spacer Bolts/Nuts - First Pass
11 Nm (97 inch lbs.)
Intake Manifold-to-Spacer Bolts/Nuts - Final Pass
22 Nm (16 ft. lbs.)
Intake Manifold Top Cover Bolts/Nuts - First Pass
6 Nm (53 inch lbs.)
Intake Manifold Top Cover Bolts/Nuts - Final Pass
12 Nm (106 inch lbs.)
Throttle Body Bolts/Nuts
22 Nm (16 ft. lbs.)
Throttle Body Studs
7.8 Nm (69 inch lbs.)
