Rear Exterior Lighting


Rear Exterior Lighting:







(1) Center High Mounted Stop Lamp (CHMSL)
(2) Radio Antenna
(3) Rear Window Defogger Grid
(4) Back Up Lamp - Right
(5) Tail Lamp Assembly - Right
(6) Park Lamp - Right Rear
(7) Object Sensor - Right Rear Corner (UD7)
(8) Object Sensor - Right Rear Middle (UD7)
(9) License Lamp - Left/License Lamp - Right
(10) Object Sensor - Left Rear Middle (UD7)
(11) Object Sensor - Left Rear Corner (UD7)
(12) Park Lamp - Left Rear
(13) Tail Lamp Assembly - Left
(14) Back Up Lamp - Left
