Scion
>>
2013
>>
FR-S F4-2.0L (FA20)
>>
Repair and Diagnosis
>>
Heating and Air Conditioning
>>
Evaporator Temperature Sensor / Switch
>>
Service and Repair
>>
Components
Components
HEATING / AIR CONDITIONING: FRONT EVAPORATOR TEMPERATURE SENSOR: COMPONENTS; 2013 MY FR-S [03/2012 -]
