Undercoating - Precautions

86subaru2

NUMBER 12-34-86

APPLICABILITY


ALL XT COUPE VEHICLES EQUIPPED WITH A POWER ANTENNA DATE 01-28-86


SUBJECT: XT COUPE UNDERCOATING PROCEDURES


THIS SERVICE BULLETIN IS FOR INFORMATION ONLY

FIGURE 1:

When undercoating any XT Coupe vehicle equipped with a power antenna, extra care must be taken not to clog the power antenna drain tube located behind the left rear wheel in the trunk floor panel (See Figure 1). Clogging the antenna drain tube may result in antenna failure.
