Fig. 7 Exploded View Of Rear Disc Brake Assembly:

Refer to Fig. 7 when performing the following procedure.
1. Raise and support vehicle.
2. Remove front wheels.
3. Remove caliper lockpin, then rotate caliper on guide pin.
4. Remove brake pads from support.
5. Reverse procedure to install noting the following:
a. Using wrench tool No. 925590000 and spacer tool No. 926440000, or equivalents, slowly rotate caliper piston until seated into caliper bore. Ensure notch in piston face is aligned with tab on brake pad backing plate.
b. Refer to Fig. 7, for tightening values.
c. After completing installation, depress brake pedal several times to seat brake pads against rotor. If pedal stroke is excessive, bleed hydraulic system as needed.
