Brake System Specifications

Brake System Specifications:

Front Brakes
Brake Pad Lining Minimum Thickness 2.0 mm (0.080 in)
Brake Rotor Diameter 296.00 mm (11.654 in)
Brake Rotor Discard Thickness 27.4 mm (1.079 in)
Maximum Allowable Lateral Runout 0.06 mm (0.002 in)
Maximum Allowable Scoring 1.50 mm (0.059 in)
Maximum Allowable Thickness Variation 0.025 mm (0.001 in)
All brake rotors have a discard dimension cast into them.

Rear Brakes
Brake Pad Lining Minimum Thickness 2.0 mm (0.080 in)
Brake Rotor Diameter 191 mm (7.520 in)
Rotor Discard Thickness 18.4 mm (0.724 in)
Maximum Allowable Lateral Runout 0.06 mm (0.002 in)
Maximum Allowable Scoring 1.50 mm (0.059 in)
Maximum Allowable Thickness Variation 0.025 mm (0.001 in)
All brake rotors have a discard dimension cast into them.
