Horn Function Circuit Check
Horn Function Circuit CheckDescriptionPerform answer-back for each operation with horn.
Component Function CheckStep 1:
Diagnosis ProcedureRegarding Wiring Diagram information, refer to [Remote Keyless Entry System: Wiring Diagram [King Cab]]
Remote Keyless Entry System [King Cab] or [Remote Keyless Entry System: Wiring Diagram [Crew Cab]].
Remote Keyless Entry System [Crew Cab]Step 1-3:
Step 3 (Continued)-4:
