Rear Wiper Motor
Fig. 32 Rear wiper motor assembly:
1.
Disconnect battery ground cable.
2.
Remove
wiper arm and rear door trim cover.
3.
Disconnect
wiper motor wire connector.
4.
Remove
wiper motor bracket attaching bolts and wiper motor and bracket,
Fig. 32.
