Transmission Control Systems: Service Precautions
PRECAUTION -
Do not open the cover or the case of the
Engine Control Module (ECM) and various computer unless absolutely necessary. (If the IC terminals are touched, the IC may be destroyed by static electricity)
ELECTRONIC CONTROL CIRCUIT
