Ground Locations

Engine Compartment (5VZ-FE):

Ground Location
EA Front Left Fender
ED Intake Manifold Left

Connector Location
EA1 Cowl Wire and Engine Room Main Wire (Right Fender)
EB1 Engine No.2 Wire and Engine Room Main Wire (Under the Engine Room R/B)
EE1 Sensor Wire and Engine Wire (Over the Cylinder Head)
EF1 Engine Wire and Sensor Wire (Over the Cylinder Head)
EG1 Engine Wire and Differential Wire (Front Differential Upper Side)

Instrument Panel:

Ground Location
IE Left Kick Panel
IF Left Kick Panel
IG Instrument Panel Brace RH
IH Right Kick Panel
II Right Kick Panel

Body (Access Cab):

Ground Location
BJ Inside of Rear Door LH
BK Inside of Rear Door RH
BL Surrounding of the Front of the Fuel Tank

Connector Location
BA1 Front Door LH Wire and Speaker Tweeter Wire LH (Inside of Front Door LH)
BB1 Frame Wire and Cowl Wire (Under the Driver's Seat)
BC1 Front Door RH Wire and Speaker Tweeter Wire RH (Inside of Front Door RH)
BD1 Frame Wire and Cowl Wire (Under the Front Passenger's Seat)
BE1 Floor Wire LH and Cowl Wire (Center of Left Rocker Panel)
BF1 Floor Wire RH and Cowl Wire (Center of Right Rocker Panel)
BG1 Floor Wire LH and Rear Door No.1 Wire LH (Under the Left Quarter Panel)
BH1 Floor Wire RH and Rear Door No.1 Wire RH (Under the Right Quarter Panel)
BI1 Cowl Wire and Seat No.1 Wire (Under the Driver's Seat)

Body (Standard Cab):

Ground Location
BL Surrounding of the Front of the Fuel Tank

Connector Location
BA1 Front Door LH Wire and Speaker Tweeter Wire LH (Inside of Front Door LH)
BB1 Frame Wire and Cowl Wire (Under the Driver's Seat)
BC1 Front Door RH Wire and Speaker Tweeter Wire RH (Inside of Front Door RH)
BD1 Frame Wire and Cowl Wire (Under the Front Passenger's Seat)
BI1 Cowl Wire and Seat No.1 Wire (Under the Driver's Seat)
