Front Fender Front Apron (Assembly)

FRONT FENDER FRONT APRON (ASSEMBLY)

REPLACEMENT




1. REMOVE RADIATOR UPPER SUPPORT
2. REMOVE FRONT FENDER FRONT APRON




3. INSTALL FRONT FENDER FRONT APRON
a. Temporarily install the new parts and measure each part in accordance with the body dimension diagram.

4. MEASURING THE ENGINE COMPARTMENT DIMENSIONS
5. INSTALL RADIATOR UPPER SUPPORT
6. APPLYING SEALER TO THE ENGINE COMPARTMENT
7. APPLYING ANTI-RUST AGENT
a. After applying the top coal layer, apply the anti-rust agent to the inside of the necked section structural weld spots.
