Component Specifications

SYSTEM DIAGRAM






Front brake disc thickness
Standard 28.0 mm (1.102 in.)
Minimum 25.0 mm (0.983 in.)
Front brake disc runout Maximum 0.05 mm (0.0020 in.)

Rear brake disc thickness
Standard 10.0 mm (0.390 in.)
Minimum 8.5 mm (0.334 in.)
Rear brake disc runout Maximum 0.15 mm (0.0059 in.)
