Reading

Additional information
- Wiring Diagrams, and Component Locations.
- Connect Scan Tool VAG 1551 and enter address word "02 transmission electronics" and advance until "Select function XX" indicated on display.

Indicated on display

Rapid data transfer HELP
Select function XX

- Press buttons -0- and -8- to select "Read measured value block" function 08.

Indicated on display

Rapid data transfer Q
08 - Read measured value block

- Confirm entry with -Q- button.

Indicated on display

Basic setting HELP
Enter display group number XXX

- Enter display group number. See List of selectable display group numbers, refer below.
- Confirm entry with -Q- button.
- There are always 4 display fields in the measured value block. Decoding the individual values in display fields 1 to 4. See "Test Tables".

Read measured value block 1 ->
->1 ->2 ->3 ->4





List of Selectable Display Group Numbers






- If the printer is switched ON, the current display is printed out.

- If the specified values are reached in all the display fields:
- Press button ->

Indicated on display:

Rapid data transfer HELP
Select function XX
