Intake Manifold - Specifications
Upper Intake Manifold Install two studs (2) to the
intake manifold support brackets (1). Tighten the studs to 12 Nm (105 in. lbs.).
Lower Intake Manifold Install the
intake manifold bolts and tighten in the sequence shown to 28 Nm (21 ft lbs).
