Distributor Vacuum Control: Testing and Inspection
Fig. 3 Lambda-sond (oxygen sensor) system vacuum hose routing:
Check vacuum hose routing,
Fig. 3. Ensure hoses are properly routed and not damaged. Replace any deteriorated or damaged hose as necessary.
