Window Shade: Service and Repair
Parcel shelf sun blind
Removing the sun visor
Remove:
- the nuts and washers from under the parcel shelf
- the sun blind assembly from the parcel shelf.
Installing the sun visor
Install:
- the screws on the sun blind
- the sun blind on the parcel shelf
- the washers and nuts. Finger tighten.
Hook the sun blind into the holder.
Adjust the sun blind to the correct position.
Tighten the screw. Tighten to 5 Nm.
