DTC 17816

Scan Tool Printer Display, Code 17816:

NOTES:
^ DTC "17816" is only displayed in vehicles equipped with an Exhaust Gas Recirculation (EGR) system.
^ DTC "17816" is stored as soon as the EGR temperature signal is less than 5°C (41°F) for longer than 45 seconds with an open closed throttle position switch, an engine coolant temperature greater than 60°C (86°F), a throttle angle less than 42.5°, a vehicle speed between 43 and 65 mph, an EGR valve duty cycle greater than 50%, an engine speed between 1500 RPM and 3000 RPM and an engine load between 16% and 60%.
