Procedures

REMOVAL PROCEDURE




1. Remove the electric mirror.
2. Remove the glass from the mirror housing.
3. Remove the mirror motor retaining screws.
4. Disconnect the electric connector.
5. Remove the motor.

INSTALLATION PROCEDURE




1. Install the motor.

NOTE: Refer to Fastener Notice in Service Precautions.

2. Install the mirror motor retaining screws.

Tighten
Tighten the electric mirror motor screws to 10 N.m (89 lb in).

3. Connect the electric connector.
4. Install the glass to the mirror housing.
5. Install the electric mirror.
