Drive Belt: Service and Repair

REMOVAL
1. Loosen the accessory drive belt tensioners (3 and 10) to reduce tension on the accessory drive belts (1 and 5).
2. Remove the accessory drive belts (1 and 5).
3. Clean the accessory drive belt surfaces.

INSTALLATION
1. Install the accessory drive belts (1 and 5).
2. Tighten the accessory drive belt tensioners (3 and 10) to increase tension on the accessory drive belts (1 and 5).
3. Inspect that the accessory drive belts are aligned in the proper pulley grooves.
