3.8L Engines

MODEL YEAR: 1984 ENGINE: 3.8L

CARBURETOR SPECIFICATIONS

Model: Motorcraft 2150
Part Number: E4SE-9510-CA (A/C) E4SE-9510-DA (Non A/C)

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .103"
Bi-Metal Identification: 2080ME350
Fast Idle Cam Setting: V-Notch
Fast Idle Cam Identification: H
Choke Plate Lever Setting: Std.
De-Choke: .25" Minimum
Choke Cap Setting: V-Notch
Choke Lever Identification: E2

FUEL INLET SYSTEM
Float Setting (Dry): 7/16"
Float Level (Wet): .810"

PUMP SYSTEM
Pump Lever Location: #3

MAIN METERING SYSTEM
Enrichment Valve Identification: Yellow
Fuel Bowl Vent Valve: 3/8" Open Tube
Main Jet: 46 F

DISTRIBUTOR SPECIFICATIONS Total Advance @ 2500 RPM Includes Initial Timing
Distributor Part No: E4AE-12127-AA
Initial Timing (~BTDC): 6
Vac Advance Connected: 32-42
Vac Advance Disconnected: 11-16

PROPANE SPECIFICATIONS (Set in Neutral)

Gain RPM: 40-100
Reset RPM: 70
