Calibration:4-25A-R10 Holley 6149-FB E43E-9510-VB

MODEL YEAR: 1984 ENGINE: 2.3L
CARBURETOR SPECIFICATIONS

Model: Holley 6149-FB
Part Number: E43E-9510-VB

CHOKE/FUEL ENRICHMENT SYSTEM
Pulldown Setting: .140-.180" w/Modulator Spring Compressed
Bi-Metal Identification: #509
Fast Idle Cam Index: .020-.030"
Fast Idle Cam Identification: 4 Step Gold
De-Choke: .180-.220"
Come-Off Time: 4 min Maximum
Choke Cap Setting: (2 NR) with Tamper Resistant Gray Spacer

FUEL INLET SYSTEM Fuel Level (Dry): Both float pontoons at outboard edge flush with surface of main body casting (without gasket)

PUMP SYSTEM
Pump Lever Location: #2
