Pinpoint Test C: High Blower Always on In All Switch Positions
II Symptom - High Blower Always On In All Switch Positions:
ElectricalRefer to the Electrical Vacuum Troubleshooting manual for a complete schematic and wire colors.
Test ConditionStart engine, set control to MAX A/C, set blower switch to MED. If blower remains in high speeds:
