Pressure Feedback Exhaust Sensor: Service and Repair

REMOVAL

Exhaust Gas Recirculation (EGR) System:

1. Locate Pressure Feedback EGR (PFE) sensor located in the rear of the intake manifold.
2. Disconnect the electrical connector from sensor.
3. Remove sensor by disconnecting hose and unsnaping sensor from retaining clip.

INSTALLATION

1. Snap PFE sensor into retaining clip and connect hose.
2. Connect the electrical connector to sensor.
