Shift Linkage: Adjustments

MANUAL SHIFT LINKAGE ADJUST

Manual Control Linkage Adjustment:

1. Position selector lever in the Overdrive position against rearward stop. Shift lever should be held in the rear-ward position while linkage is being adjusted.
2. Loosen manual lever to control cable attaching nut.
3. Place transaxle manual lever in the Overdrive position, second detent from most rearward position, then torque cable attaching nut to 11-19 ft lbs.
4. Check operation of transaxle in each selector lever position. Ensure park and neutral start switch operate satisfactorily.
