Hose and Line Replacement

Removal and Installation












1. Disconnect battery ground cable.

2. Remove drive belt.

3. Disconnect power steering pressure hose from power steering pump and drain the fluid into a container.

4. Remove power steering reservoir pump hose from between power steering pump and power steering pump reservoir. Drain fluid into a container.

7. To install, reverse Removal procedure.

8. Fill power steering pump reservoir to proper level with Premium Power Steering Fluid or equivalent meeting Ford specification ESW-M2033-F.
